1.Scope of Application
Straight-line sintering machine is applicable to the sintering operation in the ferrous metallurgy sintering process of iron and steel enterprises. It is the main equipment in the process of exhaust sintering. During the sintering operation, iron ore powder with different components and sizes, solvent, fuel, etc. are sintered into blocks, and harmful impurities such as sulfur, phosphorus, arsenic, etc. contained in the ore powder are partially eliminated.
2.Model and Specification
Specification: SD-180~SD-660
Capacity(t/h): 490~1550
3.Product Introduction
Our company is a professional manufacturer that designs and manufactures sintering machines in China. It is the drafting unit of the industrial standard JB/T2397-2010 Stainght-line Sintering Machine, and has rich experience in design, manufacturing, and service. Based on digestion and absorption of introduced technologies, NHI has continuously cultivated the independent research and development capacity of enterprises, accumulated a large number of patented technologies, and has built a batch of sintering machine series products with advanced technology, professional manufacturing, reliable performance and other characteristics. The pallet car width design covers 3m to 5.5m series, including Shougang, Baosteel, Wuhan Iron and Steel, Anshan Iron and Steel, Shagang, Jianlong, Baotou Steel, Baosteel, Nippon Steel Yonggang and other iron and steel enterprises provide sintering equipment, and the products are exported to South Korea, India, Brazil and other countries.
機（路徑：產品中心冶金機械燒結球團設備帶式燒結機）.png "圖片2-帶式燒結機（路徑：產品中心冶金機械燒結球團設備帶式燒結機）.png")
Feeding system: 1. Hearth layer unit 2. Round roller feeding unit 3. Mixture feeding Unit 4. Leveling and blank holding unit 19. Grate pressing unit
Skeleton: 17. Head skeleton 8. Middle skeleton 10. Tail skeleton
Track: 7. Head curve and tail curve of track unit
Main parts: 16. Drive unit 11. Tail unit 6. Air box unit 20. Pallet car assembling
Auxiliary parts: 5. Heat shield 18. Head seal cover 9. Rear seal cover 12. Pallet car sticky material removal unit 13. Grate rapping unit 14. 2# Ash hopper and Oil scraper 15.1# Ash hopper
4.Experiences
Experience in China: Shougang, Baotou Steel and Angang Steel projects (186 sets)
Experience Overseas: India, Brazil, Iran, etc (5 sets)
